137
OVERSIZE
BAR
ADAPTOR
•Allows 28,6 mm (1
1
/
8
”) bars to
be clamped to motorcycles,
snowmobiles and ATVs with or
without PowerMadd Pivot Riser Blocks
POWERRISER 325
PIVOTING RISERS
•One-piece design is made from
solid aluminum for superior strength
•51 mm (2”) riser is 83 mm (3,25”) wide; fits 22 mm (
7
/
8
”)
bar clamps on some ATVs that have a 83 mm (3,25”) wide
top post
•Provides dual pivot points that allow bars to be
positioned front to back and rotated up or down
•Check available cable slack before riding
•Two models available – for 22 mm (
7
/
8
”) bar clamp using
22 mm (
7
/
8
”) bars and for 22 mm (
7
/
8
”) bar clamp using
28,6 mm (1
1
/
8
”) oversized bars
POWERRISER 475
PIVOTING RISER
•One-piece design is made from solid aluminum
for superior strength
•12 cm (4,75”) width fits 22 mm (
7
/
8
”) bar clamps
on motorcycles and ATVs that have a 12 cm
(4,75”) wide top post
•Provide dual pivot points that allow handlebars
to be positioned front to back and rotated
up or down
•Check available cable slack to make sure existing
cables will work with the riser
•Available in 51 mm (2”) and 76 mm (3”) heights
•Two models available – for 22 mm (
7
/
8
”) bar clamp using 22 mm (
7
/
8
”) standard bars and for
22 mm (
7
/
8
”) bar clamp using oversized 28,6 mm (1
1
/
8
”) bars
DESCRIPTION
PART #
51 MM (2”) RISE POWERRISER 475
For 22 mm (
7
/
8
”) clamps to 22 mm (
7
/
8
”) bars
0602‑0244
For 22 mm (
7
/
8
”) clamps to 28,6 mm (1
1
/
8
”) bars
0602‑0245
76 MM (3”) RISE POWERRISER 475
For 22 mm (
7
/
8
”) clamps to 22 mm (
7
/
8
”) bars
0602‑0246
DESCRIPTION
PART #
76 MM (3”) RISE POWERRISER 475 (CONT)
For 22 mm (
7
/
8
”) clamps to 28,6 mm (1
1
/
8
”) bars
0602‑0247
HANDLEBAR CLAMP
For machines with one‑piece OEM handlebar clamps
0602‑0241
DESCRIPTION
PART #
POWERRISER 325
For 22 mm (
7
/
8
”) clamps to 22 mm (
7
/
8
”) bars
0602‑0242
For 22 mm (
7
/
8
”) clamps to 28,6 mm (1
1
/
8
”) bars
0602‑0243
HANDLEBAR CLAMP
For machines with one‑piece OEM handlebar clamps 0602‑0241
DESCRIPTION
PART #
Universal 76 mm (3”) Pivot Adapter/Riser 0602‑0098
Universal Riser Block 25 mm (1”)
0602‑0133
DESCRIPTION
PART #
Universal Riser Block 51 mm (2”)
0602‑0134
Universal Riser Block 76 mm (3”)
0602‑0099
UNIVERSAL
PIVOT
RISER SYSTEM
•Works on all brands with flat steering post
•Universal Pivot Riser raises bars 76 mm (3”)
and can be used without additional riser blocks
•Dual pivot points allow for bars to be positioned
front to back and rotated up or down
•Use additional riser blocks to increase bar height
an additional 76 mm (3”), 15 cm (6”) or 23 cm (9”)
PART #
0632-0202
DESCRIPTION
PART #
Elite riser for 22 mm (
7
/
8
”) bar clamps and either 22 mm (
7
/
8
”)
or 28,6 mm (1
1
/
8
”) handlebars
0602‑0362
Riser for 28,6 mm (1
1
/
8
”) bar clamp and 28,6 mm (1
1
/
8
”) handlebars
0602‑0644
ELITE SERIES
ANTI-VIBRATION 51 MM
(2”) PIVOT RISERS
•Independent left and right risers adapt to any
handlebar clamp width and therefore virtually
any machine with 22 mm (
7
/
8
”) bar clamps
•Anti-Vibe design reduces vibration in bars
•Provides a slight shock damping effect to help protect rider and machine
•Dual rotation points allow rider to select optimum riding position for
comfort and control
•Rox Elite Series risers allow you to clamp 22 mm (
7
/
8
”) or 28,6 mm (1
1
/
8
”)
taper bars
•Engineered and tested for maximum strength and durability
•CNC-machined from billet 6061 T-6 aluminum anodized gold
Patent # US 6,920,806 BZ.
NOTE: Confirm you have sufficient clearance between Anti-Vibe bolt and cowl when
turned full left or right; bolt extends below OE saddle clamp 22 mm (
7
/
8
”).
NOTE: Longer cables may be required when installing handlebar risers.
51 MM (2”) PIVOTING RISERS
FOR 22 MM (
7
/
8
”) HANDLEBARS
•Patented design pivoting risers are incredibly universal with a two-piece
design that allows them to be clamped to any motor vehicle with 22 mm
(
7
/
8
”) handlebar clamps
•Risers are held by the original clamps and re-clamp the handlebars 51 mm
(2”) higher with pivoting fore and aft adjustment
•Rox out-board positioning also makes them incredibly durable
•Available in black or natural
aluminum finish
•Made in the U.S.A.
NOTE: Longer cables may be required
when installing handlebar risers.
0602‑0244
0602‑0247
0602‑0246
0602‑0245
0602‑0244
0602‑0241
0602‑0242
0602‑0243
0602‑0241
0602‑0439
0602‑0296
0602‑0362
Universal pivot without
additional riser block
Powermadd
provided
caps
Stock caps
DESCRIPTION
PART #
Black
0602‑0296
Natural aluminum
0602‑0439
