133
T2 HANDLEBARS (CONT)
PART #
0603-0545
UNIVERSAL BAR MOUNT KIT
•For triple clamps with a one-piece design and stock bar mounts that can’t
be removed
•Allows you to go from stock 22 mm (
7
/
8
”) bars and run oversized bars
•Machined from 6061-T6 aluminum
•Raises bars 17 mm (
2
/
3
”) over stock height
•22 mm (
7
/
8
”) to 28,6 mm (1
1
/
8
”) conversion
NOTE: Should not be used with rubber-mounted clamps
DESCRIPTION
PART #
For Honda or Kawasaki
0603-0547
For Honda or Kawasaki, plus 10mm
0603-0548
For Tag Metals triple clamps; fit 22,2 mm (
7
/
8
”) handlebars
0603-0546
28,6 MM (1
1
/
8
”)
HANDLEBAR MOUNTS
FOR OEM CLAMPS
•Designed to replace OEM rubber
and solid mounts
•Available for 22 mm (
7
/
8
”) bars or oversized 28,6 mm (1
1
/
8
”) XT-1, T2 or any
other brand over-sized bars
•Machined from 6061-T6 aluminum
DESCRIPTION/BEND
PART #
COLOR
WIDTH
HEIGHT
RISE
CLAMP
SWEEP
STANDARD
James Stewart
0601‑2477
Black
800
84
56
210
52
Windham/Yamaha
0601‑2491
Black
803
92
56
210
57
Hon/Kaw/RC/Fac (971)
0601‑2497
Black
802
99
65
200
54
Hon/Kaw/RC (971) High
0601‑2465
Black
802
119
80
200
54
CR Low
0601‑2485
Black
796
80
55
210
57
0601‑2486
Silver
796
80
55
210
57
CR High/KTM/ATV
0601‑2471
Black
795
95
70
205
62
Mini Race
0601‑2481
Black
740
118
83
175
42
Jr. Mini Racer
0601‑2463
Black
750
88
62
117
50
Mini Playbike
0601‑2476
Black
722
185
112
170
63
Raptor/Banshee
0601‑2464
Black
785
140
105
155
100
ANTI‑VIBRATION
Windham/Yamaha
0601‑2523
Black
803
92
56
210
57
Hon/Kaw/RC/Fac (971)
0601‑2521
Black
802
99
65
200
54
Hon/Kaw/RC (971) High
0601‑2520
Black
802
119
80
200
54
ATV EX/Hon. 450/Suz. LTZ
0601‑2518
Black
790
142
105
200
90
CR High/KTM/ATV
0601‑2519
Black
795
95
70
208
62
Mini Racer
0601‑2522
Black
750
88
62
117
50
X5 HANDLEBARS
•22 mm (
7
/
8
”) bar extruded from aerospace-grade 2014-T6 aluminum
•Crossbar added for extra strength and “crossbar feel”
•Double-butted aluminum design provides extra strength and saves weight where needed
•Anodized and shot-peened finish adds comprehensive layer for maximum durability
•Laser-etched positioning grid is impervious to wear and chemicals
•Knurled left grip area reduces slippage
•Foam bar pad with vinyl cover included
•Anti-vibration bars include patent-pending Glass Microsphere technology that reduces arm pump
DESCRIPTION/BEND
PART #
COLOR
WIDTH
HEIGHT
RISE
CLAMP
SWEEP
STANDARD (CONT)
CR High/KTM/ATV
0601‑2472
Black
795
95
70
205
62
0601‑2473
Silver
795
95
70
205
62
0601‑2474
Nitride
795
95
70
205
62
Factory Low
0601‑2470
Black
800
92
67
200
47
MiniRacer
0601‑2482
Black
740
118
83
175
42
0601‑2483
Silver
740
118
83
175
42
ANTI‑VIBRATION
Windham/Yamaha
0601‑2516
Black
803
92
56
210
57
0601‑2517
Viridian
803
92
56
210
57
RC Low
0601‑2514
Black
800
77
45
195
52
0601‑2515
Viridian
800
77
45
195
52
Hon/Kaw/RC/Fac (971)
0601‑2512
Black
802
99
65
200
54
0601‑2513
Viridian
802
99
65
200
54
Hon/Kaw/RC (971) High
0601‑2510
Black
802
119
80
200
54
0601‑2511
Viridian
802
119
80
200
54
CR High/KTM/ATV
0601‑2508
Black
795
95
70
205
62
0601‑2509
Viridian
795
95
70
205
62
0603‑0547
