PRO-OFFSET ELITE
BLOCK RISERS
•Unique design allows for installation in either direction
•25,4 mm (1”) offset means bar can be moved closer or further away,
depending on rider preference
•Reducers lock into risers to ensure no slippage between components
•Rox Pro-Offset risers have an oblong hole so that they will fit virtually
any fore and aft bolt center-to-center distance with 8 mm bolt threads
•Made in the U.S.A.
NOTE: First determine if you have adequate brake line/cable length and stem
clamp clearance before installing handlebar risers. Longer cables may be
required when installing handlebar risers on some models.
ELITE PIVOTING RISERS FOR
22 MM (
7
/
8
”) OR 28,6 MM
(1
1
/
8
”) HANDLEBARS
•Patented design pivoting risers are incredibly
universal with a two-piece design that allows them
to be clamped to any machine with 22 mm (
7
/
8
”) handlebar clamps
•Allow you to clamp a stock 22 mm (
7
/
8
”) diameter handlebar, or you can
remove the 22 mm (
7
/
8
”) reducers and clamp a 28,6 mm (1
1
/
8
”) aluminum
handlebar; reducers lock into risers to ensure no slippage between
components, and serrated teeth provide maximum gripping power
on the handlebar
•Risers are held by the original 22 mm (
7
/
8
”) clamps and reclamp the
handlebars 51 mm (2”), 89 mm (3
1
/
2
”), or 127 mm (5”) higher (depending on
size purchased) with pivoting fore and aft adjustment
•Rox out-board positioning also makes them incredibly durable
•Available in natural aluminum or black finish
•Made in the U.S.A.
NOTE: Longer cables may be required when installing handlebar risers.
50,8 MM (2”) DELUXE
RISERS FOR 22 MM
(
7
/
8
”) HANDLEBARS
•Fits most applications with 22 mm (
7
/
8
”)
handlebars and a 22 mm (
7
/
8
”) bar clamp
•Sleek, stylish design
•Machined from billet 6061 T-6 aluminum
•Anodized clear finish
•Made in the U.S.A.
NOTE: First determine if you have adequate brake line/cable length and stem
clamp clearance before installing handlebar risers. Longer cables may be
required when installing handlebar risers on some models.
138
RISE
HANDLEBAR SIZE
FINISH
PART #
32 mm (1
1
/
4
”)
22 mm (
7
/
8
”) or 28,6 mm (1
1
/
8
”)
Clear anodized
0602‑0654
32 mm (1
1
/
4
”)
22 mm (
7
/
8
”) or 28,6 mm (1
1
/
8
”)
Black anodized
0602‑0657
PART #
0602-0655
32 MM (1
1
/
4
”)
ROX BLOCK RISER
•Block riser sits on top of OEM supporting
handlebar clamp and raises the bars
32 mm (1
1
/
4
”)
•Blocks feature oversize holes to fit a wide
array of applications. Holes measure 11,1 mm
(0,437”) diameter; 33 mm (1,300”)
center-to-center
•Natural aluminum finish
•Made in the U.S.A.
PART #
0602-0656
DESCRIPTION
COLOR
PART #
51 mm (2”) rise
Natural aluminum
0602-0365
Black
0602-0440
89 mm (3
1
/
2
”) rise
Black
0602-0441
127 mm (5”) rise
Black
0602-0442
RISE
HANDLEBAR SIZE
FINISH
PART #
44,5 mm (1
3
/
4
”)
28,6 mm (1
1
/
8
”)
Clear anodized
0602‑0438
44,5 mm (1
3
/
4
”)
28,6 mm (1
1
/
8
”)
Black anodized
0602‑0658
50,8 mm (2”)
28,6 mm (1
1
/
8
”)
Natural aluminum 0602‑0437
RISE
HANDLEBAR SIZE
FINISH
PART #
50,8 mm (2”)
28,6 mm (1
1
/
8
”)
Clear anodized
0602‑0651
50,8 mm (2”)
28,6 mm (1
1
/
8
”)
Gray anodized
0602‑0652
50,8 mm (2”)
28,6 mm (1
1
/
8
”)
Black anodized
0602‑0653
ROX PIVOTING HANDLEBAR RISER FOR 28,6 MM (1
1
/
8
”) HANDLEBARS
•Very popular addition for the BMW R1200GS, R1200GSA, HP2, and KTM 690 Enduro
•Also fits many other street, off-road, and dual sport models with a 28,6 mm (1
1
/
8
”) stem clamp and a 28,6 mm (1
1
/
8
”) handlebar
•Handlebar clamps can be pivoted to desired fore and aft location to achieve ideal riding position
•Engineered and tested for maximum strength and durability
•CNC-machined from billet 6061 T-6 aluminum, then anodized for long-lasting good looks
•Made in the U.S.A.
NOTE: First determine if you have adequate brake line/cable length, and stem clamp clearance before installing handlebar risers. Longer cables may be required when
installing handlebar risers on some models.
OVERSIZE HANDLEBAR CLAMP KIT
•Universal clamp allows 28,6 mm (1
1
/
8
”) bars to be clamped to ATVs,
snowmobiles and motorcycles
•Works with PowerMadd and stock OEM pivot-style riser blocks
•Available in black
Note: Will also work on snowmobiles with flat-style
steering posts, ATVs and dirt bikes.
PART #
0603-0263
0602‑0651
0602‑0652
0602‑0658
0602‑0438
0602‑0654
0602‑0365
0602‑0441
0602‑0657
