Variable air volume controllers
|
67
Basic functions
Device-specific identification
Key
Display examples
(Read
only)
Explanation
LMV-D3-MP
Office 2.12 Supply air
Type designation of the actuator/VAV controller
Position (16 characters) optional
–
LMV-D3-MP
DN160 / xxx
Type designation of the actuator/VAV controller
Designation (16 characters) optional
+
LMV-D3-MP
FW: Vxx.xx.00
Type designation of the actuator/VAV controller
Firmware version of the actuator/VAV controller
OK
Address: xx
0073040033146142
MP address MP1 … 8 / PP (PP: no bus operation)
Serial number of the actuator/VAV controller
Position and Designation (16 characters) optional.
These display options can be described with the PC-Tool if required.
Set the MP bus address Key Display examples
(Read/
write)
Explanation
▲
MP address: PP
-new: MP1
Active setting (PP: no bus operation)
Set the desired address MP1…8 (OK)
Configuration
Start Configuration
1. Press the key (OK) while simultaneously plugging in the connecting cable
2. Configuration menu display appears
Configuration Menu Option / Display
Setting
Product
range
Explanation
HW Version Vx.x
FW Version Vx.x
Display of the current hardware and
firmware version of the ZTH-GEN
Text
German /
English
-
VAV unit
m
3
/h
/ l/s / cfm
VAV
EPIV unit
m
3
/h /
l/min
/ gpm Valves
Supply. …
AC … V VHW: … %
Display of the current AC 24V
supply voltage, with direct
connection to terminals (ZK2-GEN)
Start MP tester
OK
-
MP bus diagnostics tool for system
integrators.
The MP tester is not part of this
documentation.
PICCV function
0
/ 1
Valves
Belimo US
Enable PICCV Wizard function
Expert Mode
1)
0
/ 1
VAV
Enable VAV settings:
– Switching mode,
– set
min /
max to original values
(call up OEM setting)
Advanced Mode
2)
0
/ 1
VAV
Fire
protection
Enable settings:
– VAV: Direction of rotation,
– BF-Top: Adaption
Exit Configuration
OK
Activate options 1) and 2) only as needed and with the respective know-how; the adjustment of the
respective parameters requires special expertise.
